Deskripsi

Soundcraft Nano M16

Original 100%

Garansi resmi 1 Tahun PT. IMS

NANO Series multi-channel analog mixing console inherits legendary SOUNDCRAFT craftsmanship and is designed to meet various application requirements from live performance, studio recording and fixed installations. NANO Series owns two models in its product portfolio: M16 (16 channels) and M24 (24 channels) and represents a new level of design, quality and performance.

SPECIFICATIONS

Noise

Hum & noise : <-80 dB @ 20 Hz~22 KHz A-weighted, 1 channel & main level: 0 dB, the other: minimum Crosstalk Crosstalk : <-80 dB @ 0 dB 20 Hz~22 KHz A-weighted, main level: 0 dB, the other: minimum Frequency Response Mic/Line Input to any output, 20 Hz-20 kHz :
THD + N

Mic sens. -30 dBu, +20 dBu at all outputs @ 1 kHz :
CMRR

Typical @ max gain @ 1 kHz : >80 dB

Typical @ any gain @ 50 Hz : >60 dB

Input & Output Impedance

Mic Input : 1.8 kΩ

Line Input : 23.6 kΩ

Stereo Input : 20 kΩ

Mix, Aux and Insert Sends : 120 Ω

Input & Output Levels

Mic Input max. level : +20 dBu

Line Input max. level : +30 dBu

Stereo Input max. level : +30 dBu

Headphones (@ 200 Ω) : 150 mW

Compressor

Gain : 0 – 9 dB

Threshold : 20 dB →↓5 dB

USB 2.0 (Standard B)

Inputs / Outputs : 2-in, 2-out

Bit Depth : 16-bit

Sampling rate : 32 kHz / 44.1 kHz / 48 kHz

USB Player

Inputs / Outputs : 2-in, 2-out

Record sampling rate : 44.1 kHz

Power Consumption

Mains voltage : 100 V-240 VAC, 50/60 Hz, universal input

Physical

Net weight : 6.59 kg

Gross weight : 8.2 kg

Dimensions : 504.62 x 425.00 x 88.34 mm

FEATURES

* Ultra-low noise discrete MIC preamp with +48V phantom power.
* 8 / 16 mono input channels and 4 stereo input channels.
* Each input channel accepts balanced XLR MIC input and TRS LINE input.
* Low cut for each MIC input.
* Each mono input channel is equipped with 3-band EQ, sweepable MID and PEAK LED.
